Tailift ZFB30P Z Series 4 Wheel Electric Forklift

CHARACTERISTICS

• Load capacity: 6,000 lbs at 24″ load center
• Length (w/o forks): 97.3
• Width: 49.6 in
• Height (overhead guard): 84.5 in
• Travel speed (laden): 7 mph
• Travel speed (unladen): 8.6 mph
• Lift speed (laden): 57 fpm
• Lift speed (unladen): 98.4 fpm
• Turning radius: 84.3 in
• Controller: ZAPI
• Battery (min.capacity): 560 AH/5HR

Easy Operation

A large and easy-to-read multifunctional LCD panel is ergonomic designed for the operator.

Optional advanced hydraulics Minlever and joystick with armrest are all new design gives more comfort to the operator.

• The ergonomic design of levers is providing the prefect positions for operator ‘s hand without causing any extra stress.
• Multifunction armrests with F/R control lever make forward and reverse easier.

High Stability

Our new hydraulic lock out system option which automatically lock off all hydraulic functions and transmission drive if it has not detected the presence of the operator.

A strong no-bolt integral heavy-duty chassis gives the driver 20% more protection from falling loads. Tailift forklifts built with Integral heavy-duty chassis， suite for all kind working surface.

• The new axle provides wider steering angles to 85 degree and reduces to a smaller turning radius.
• Its compact size allows the truck to work in narrower aisles.
• Using high and low blockage fixed way to fix shaft， extend working lifetime and lower maintenance cost.
• Grease nipples located on the contact points will save time and cost to do maintenance.

• Smaller steering wheel (300mm) easy to operate and reduce operator ‘s arm and shoulder’s workload.
• The easy-handling steering wheel column with tilt adjustment.

Easy Service

• Side battery access Side battery access is easy remove or exchange the truck battery facilitating.
• Rear service panel Rear service panel are easy remove for quick service check and repair.
• Centralized fuse box A centralized fuse box for easy inspection.
